Low Noisy 4mm Wire Straightening And Cutting Machine

Brand Name : JINTE

Model Number : JT-S

Certification : ISO

Place of Origin : China

MOQ : 1 set

Price : USD7800-12000 / SET

Payment Terms : L/C, T/T, Western Union

Delivery Time : 25days

Packaging Details : Packed in container with fixed iron rope and wooden stick. Necessarily, the machine will also be paint oil and plastic film. Train transport or sea way are both ok.

Machine name : straightening and cutting machine automatic

Wire diameter : 12-16mm,16-18mm.16-20mm

Diameterof rebar : 10-14mm,14-16mm,14-18mm

Speed : 108-130m/ min

Weight : 2.1T

Contact Now

Automatic wire straightening and cutting machine/steel bar straightening and cutting machine

Features:

Product Description

This kind of machine has four specifications, and the diameter is from 1.5 to 12mm
The length could adjust according to customers demand. It could straighten stainless steel wire, aluminum wire, cold-drawing wire, and steel wire with plastics. This machine has many advantages, such as neat cutting mouth,easy to operation,low noisy, less error and good functions.

Low Noisy 4mm Wire Straightening And Cutting Machine

Low Noisy 4mm Wire Straightening And Cutting Machine

Low Noisy 4mm Wire Straightening And Cutting Machine

TECHNICAL PARAMETERS

Model
JT-SC-A
JT-SC-B
JT-SC-C
JT-SC-D
JT-SC-E
JT-SC-F
JT-SC-G
Dia (mm)
1-3
2-6
3-8
3-8
6-12
8-12
8-14
Cutting length (mm)
30-2000
30-6000
200-6000
200-6000
600-12000
600-12000
700-9000
Cutting Error (mm)
±1
±1
±1
±1
±10
±10
±10
Speed (m/min)
25
30
35
40
30
40
40
Motor (kw)
1.5
1.5
4
4.5
7.5
45
45
Weight (kg)
130
150
650
700
1000
1200
1000
Outside (m)
1.7*0.5*0.8
1.2*0.5*0.9
7.3*0.7*1.3
8*0.8*1.4
2.2*0.8*1.4
1.9*0.7*1.4
1.8*0.8*1.5

We also able to manufacture machines according to orders, please feel free to let us know if your have special requirements.
